Size	1.5 inch
Pixels	120 × 240
Interface	MIPI DSI , SPI
Brightness	350 cd/m² typ (300 cd/m² min @ θ=0°)
Manufacturer	Gesight
Display Type	Flexible OLED
Display Mode	–
Color Depth	16.7M colors
Refresh Rate	60 Hz
Viewing Angle Range	80° (Top/Bottom/Left/Right, condition CR > 1600)
Outline LWH	20.12 × 38.94 × 0.71 mm (typ, Module Size w/o COF & FPCa & CAF; Thickness typ)
Active Area L*W	16.92 × 33.84 mm
Orientation	Landscape
Supply Voltage	VCI: 2.8 V typ (2.7–3.6 V); VDDIO: 1.8 V typ (1.65–3.3 V); ELVDD: 4.6 V typ (4.55–4.65 V); ELVSS: −2.4 V typ (−2.35 to −2.45 V)
Consumption	110 mW typ; IC: 14.24 mW typ
Operating Temperarure	−20 to +60 °C
Storage Temperature	−30 to +70 °C
Bezel Area (mm)	H bezel total 3.20 mm (≈1.60 mm per side); V bezel total 5.10 mm (≈2.55 mm per side)
Aspect Ratio	1:2 (120:240)
Connection Type	I-PEX connector: 20641-024E (module); mating/user connector: 20642-024E
IC package	COF
Touch Panel	Need to make
Pixel Pitch	0.141(H) × 0.141(V) mm
Sunlight Readable	–
Model	GO15F120SPI
PPI ( pixels per inch )	180 PPI
Application	Smart bracelet

Size	1.9 inch
Pixels	170(RGB) × 320
Interface	SPI
Brightness	Typ. 330 cd/m²（If=20mA)
Manufacturer	Gesight
Display Type	TFT-LCD
Display Mode	IPS / Transmissive / Normally Black
Color Depth	262K colors (18-bit)
Refresh Rate	60Hz
Viewing Angle Range	H: 80°/80°，V: 80°/80°（CR≥10）
Outline LWH	25.8(H) × 49.72(V) × 1.43(T) mm
Active Area L*W	22.7(H) × 42.72(V) mm
Supply Voltage	VDD: 2.4–3.3V（Typ 2.8V）; VCI: 2.4–3.3V（Typ 2.8V）; IOVDD: 1.65–3.3V（Typ 1.8/2.8V）
Consumption	Normal display Ivdd: Typ 50 mA；Standby Ivdd: Typ 20 µA
Operating Temperarure	-20 ~ 70 ℃
Storage Temperature	-30 ~ 80 ℃
Bezel Area (mm)	–
Aspect Ratio	17:32
Connection Type	–
IC package	–
Touch Panel	Need to make
Orientation	Portrait
Pixel Pitch	≈ 0.1335 mm
Sunlight Readable	–
Model	PL19006C30
PPI ( pixels per inch )	≈ 191 PPI
Application	–

Size	2.45" (Diagonal)
Pixels	240× 432
Interface	MIPI DSI
Brightness	450 ~ 500 cd/m²
Manufacturer	Gesight
Display Type	IPS LCD , TFT-LCD
Display Mode	ECB, Normally White
Color Depth	262K colors (18-bit)
Refresh Rate	30 fps (typical at 240 Mbps MIPI)
Viewing Angle Range	≥50° each direction (CR≥10)
Outline LWH	31.82 × 33.72 × 1.242 mm
Active Area L*W	30.24 × 54.432 mm
Orientation	Portrait
Supply Voltage	Logic: 1.8 V, Analog: 3.0 V
Consumption	Backlight: ~252 mW, MIPI logic: up to 40 mW
Operating Temperarure	–20°C ~ 70°C
Storage Temperature	-30°C ~ +80°C
Bezel Area (mm)	(Not explicitly listed; approx. outline – active area margins)
Aspect Ratio	9:16
Connection Type	FPC (flex cable)
IC package	COG (Chip on Glass)
Touch Panel	Need to make
Pixel Pitch	0.042 × 0.126 mm
Sunlight Readable	Partial (≥500 cd/m², but not full outdoor readability)
Model	H245QBN02.0
PPI ( pixels per inch )	~180 PPI
Application	Handheld devices, portable instruments, smart appliances

Size	2.6 inch
Pixels	240 × RGB × 320
Interface	SPI
Brightness	200 cd/m² (Typ), 170 cd/m² (Min), 230 cd/m² (Max)
Manufacturer	Gesight
Display Type	AMOLED
Display Mode	AMOLED
Color Depth	262K (6-bit)
Refresh Rate	80 Hz (Frame Rate setting in test condition)
Viewing Angle Range	160° (Min), 170° (Typ)
Outline LWH	44.7 × 62.2 × 1.65 mm (Typ)
Active Area L*W	39.60 × 52.48 mm
Orientation	Landscape
Supply Voltage	AR_VDD = +4.6 V; AR_VSS = -4.4 V; VCI = 2.5–3.3 V; IOVCC (VDD3) = 1.65–3.3 V
Consumption	260 mW (Typ), 300 mW (Max) @ 30% pixels on
Operating Temperarure	−30 to +70 °C
Storage Temperature	−40 to +80 °C
Bezel Area (mm)	L/R = 2.55 mm; T/B = 4.86 mm (calculated from Outline vs Active Area)
Aspect Ratio	3:4 (240:320)
Connection Type	–
IC package	COG assembly
Touch Panel	Need to make
Pixel Pitch	0.055 × 0.164 mm
Sunlight Readable	–
Model	AMS260DN01
PPI ( pixels per inch )	154 PPI
Application	Cell phone etc.
