High Brightness refers to displays designed to deliver strong luminance output so content remains clear in bright ambient light. By increasing panel brightness and optimizing contrast, high-brightness screens improve readability for text, icons, and critical UI elements in challenging conditions such as sunlight, reflective environments, or brightly lit indoor spaces. This helps reduce eye strain and makes information easier to recognize at a glance.
High-brightness designs often pair elevated luminance with supporting features such as anti-reflective or anti-glare surface treatments, high-transmittance optical stacks, and stable backlight or emissive control for consistent output over time. They’re commonly used in outdoor kiosks, handheld terminals, marine and aviation displays, vehicle dashboards, industrial HMIs, and portable monitors—anywhere reliable visibility is essential for safety, productivity, and user comfort.
FREE SHIPPING
Fast and reliable delivery
50 DAYS RETURN
Consumer protection program
24/7 SUPPORT
If you have any questions
BEST QUALITY
Many years on the market
0.71-inch FHD Micro OLED display 3000 nits
| Size |
0.71 inch |
|---|---|
| Pixels |
1920(RGB) × 1080 |
| Interface | |
| Brightness |
3000 cd/m2 (Typ., Mode 4) |
| Manufacturer |
Gesight |
| Display Type |
Micro OLED |
| Display Mode |
Active Matrix Color OLED (AMOLED) |
| Color Depth | |
| Refresh Rate |
60 Hz (also supports 50 Hz / 48 Hz modes) |
| Viewing Angle Range |
– |
| Outline L*W*H |
37.32 mm × 21.443 mm × 1.475 mm |
| Active Area L*W |
15.8 mm × 8.99 mm |
| Orientation | |
| Supply Voltage |
VDD1: 1.62–1.98 V (Typ. 1.8 V); VDD1IF: 1.62–1.98 V (Typ. 1.8 V); VDD2: 9.7–10.3 V (Typ. 10.0 V); VCATH: -0.3–0.3 V (Typ. 0 V) |
| Consumption |
Total power (Typ.): 1280 mW @ 3000 cd/m2 (All white, 60 Hz) |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−30 to +80 °C |
| Bezel Area (mm) |
– |
| Aspect Ratio |
16:9 |
| Connection Type |
FPC, 81-pin (P0.2 mm pitch) |
| IC package |
– |
| Touch Panel | |
| Pixel Pitch |
0.00819 mm |
| Sunlight Readable |
– |
| Model |
ECX335SN-6 |
| PPI ( pixels per inch ) |
3103 PPI |
| Application |
Head mounted displays; View finders; Small monitors |
2.1 inch TFT-LCD 1600×1600 MIPI For VR
| Size |
2.1inch |
|---|---|
| Pixels |
1600(H) × 1600(V) |
| Interface | |
| Brightness |
Min 360 / Typ 450 cd/m² |
| Manufacturer |
Geisght |
| Display Type |
IPS LCD ,TFT-LCD |
| Display Mode |
Transmission mode, Normally Black |
| Color Depth | |
| Refresh Rate |
70 / 90 Hz |
| Viewing Angle Range |
CR > 100: Left/Right 40°, Up/Down 40° |
| Outline L*W*H |
41.2(H) × 45.3(V) × 1.66(T) mm |
| Active Area L*W |
38.40 × 38.40 mm |
| Orientation | |
| Supply Voltage |
VDDI: 1.7 / 1.8 / 1.9 V (Min/Typ/Max); AVDD: 5.7 / 6.0 / 6.3 V; AVEE: -6.3 / -6.0 / -5.7 V |
| Consumption |
IVDDI: Typ 79.8 mA / Max 87.7 mA; IAVDD: Typ 8.7 mA / Max 12 mA; IAVEE: Typ -5.4 mA / Max -11 mA; Backlight Power PBL: Typ 468 mW (20% duty) |
| Operating Temperarure |
−10~55°C |
| Storage Temperature |
−40~70°C |
| Bezel Area (mm) |
– |
| Aspect Ratio |
1:1 |
| Connection Type |
Connector: Kyocera 145863050024829+ |
| IC package |
– |
| Pixel Pitch |
8(H) × 24(V) μm |
| Sunlight Readable |
– |
| Model |
VS021XRM-NW0-DKP0 |
| PPI ( pixels per inch ) |
1058 |
2.45 Inch TFT LCD Display High Brightness Wide Viewing Angle
| Size |
2.45" (Diagonal) |
|---|---|
| Pixels |
240× 432 |
| Interface | |
| Brightness |
450 ~ 500 cd/m² |
| Manufacturer |
Gesight |
| Display Type |
IPS LCD ,TFT-LCD |
| Display Mode |
ECB, Normally White |
| Color Depth | |
| Refresh Rate |
30 fps (typical at 240 Mbps MIPI) |
| Viewing Angle Range |
≥50° each direction (CR≥10) |
| Outline L*W*H |
31.82 × 33.72 × 1.242 mm |
| Active Area L*W |
30.24 × 54.432 mm |
| Orientation | |
| Supply Voltage |
Logic: 1.8 V, Analog: 3.0 V |
| Consumption |
Backlight: ~252 mW, MIPI logic: up to 40 mW |
| Operating Temperarure |
–20°C ~ 70°C |
| Storage Temperature |
-30°C ~ +80°C |
| Bezel Area (mm) |
(Not explicitly listed; approx. outline – active area margins) |
| Aspect Ratio |
9:16 |
| Connection Type |
FPC (flex cable) |
| IC package |
COG (Chip on Glass) |
| Touch Panel | |
| Pixel Pitch |
0.042 × 0.126 mm |
| Sunlight Readable |
Partial (≥500 cd/m², but not full outdoor readability) |
| Model |
H245QBN02.0 |
| PPI ( pixels per inch ) |
~180 PPI |
| Application |
Handheld devices, portable instruments, smart appliances |
2.4-inch 450×600 AMOLED Display Module
| Size |
2.4 inch |
|---|---|
| Pixels |
450RGB × 600 |
| Interface | , , |
| Brightness |
800 cd/m² (typ.) |
| Manufacturer |
Gesight |
| Display Type |
AMOLED |
| Display Mode |
AMOLED |
| Color Depth | |
| Refresh Rate |
60 Hz |
| Viewing Angle Range |
80° (Left/Right/Top/Bottom, CR ≥ 10) |
| Outline L*W*H |
38.72 × 51.56 × 0.5 mm |
| Active Area L*W |
36.72 × 48.96 mm |
| Orientation | |
| Supply Voltage |
VCI: 2.7–3.6 V (typ. 3.3 V); VDDIO: 1.65–3.3 V (typ. 1.8 V); ELVDD: 2.0–6.0 V (typ. 3.6 V); ELVSS: -4.7–-0.4 V (typ. -3.6 V) |
| Consumption |
TBD (spec lists power as TBD; IELVSS typ. 72.2 mA in on-mode condition) |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−40 to +80 °C |
| Bezel Area (mm) |
– |
| Aspect Ratio |
3:4 |
| Connection Type |
FPC (mating connector: Molex 502598-4591) |
| IC package |
COF |
| Touch Panel | |
| Pixel Pitch |
81.6 um |
| Sunlight Readable |
– |
| Model |
B024JMV-N50-6DP0 |
| PPI ( pixels per inch ) |
311 PPI |
| Application |
Sports camera; Smart home |
3.16-inch TFT-LCD Display Module 820×320 Parallel RGB
| Size |
3.16 inch |
|---|---|
| Pixels |
820 RGB × 320 |
| Interface | |
| Brightness |
550 cd/m² (typ.) |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Transmission mode, Normally black |
| Color Depth | |
| Refresh Rate |
– |
| Viewing Angle Range |
80° (CR ≥ 10) for each direction (U/D/L/R) |
| Outline L*W*H |
76.6 × 31.2 × 2.4 mm |
| Active Area L*W |
65.65 × 26.4 mm |
| Supply Voltage |
VCI: 2.8–3.6 V (typ. 3.3 V); IOVCC: 1.65–3.3 V (typ. 1.8 V) |
| Consumption |
Idd: 40 mA (typ.) |
| Operating Temperarure |
-20 to 70 °C |
| Storage Temperature |
-30 to 80 °C |
| Bezel Area (mm) |
5.475 mm (left/right), 2.4 mm (top/bottom) |
| Aspect Ratio |
820:320 |
| Connection Type |
– |
| IC package |
– |
| Touch Panel | |
| Orientation | |
| Pixel Pitch |
0.0825 × 0.0285 mm |
| Sunlight Readable |
– |
| Model |
PL0316IV0-SV1-RGB |
| PPI ( pixels per inch ) |
278.6 PPI (≈279 PPI) |
| Application |
Virtual Reality Device；Augmented Reality Device |
4.0-inch Square TFT-LCD Display Module 480×480 SPI+RGB
| Size |
4.0inch |
|---|---|
| Pixels |
480(RGB) × 480 |
| Interface | , |
| Brightness |
420 min / 450 typ cd/m² |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Normally Black |
| Color Depth | |
| Refresh Rate |
60 Hz |
| Viewing Angle Range |
80° (T) / 80° (B) / 80° (L) / 80° (R), CR ≥ 10 |
| Outline L*W*H |
84.3 * 84.3 * 3.2 mm |
| Active Area L*W |
71.86 * 70.18 mm |
| Supply Voltage |
VDD = 2.8 min / 3.3 typ / 3.6 max V |
| Consumption |
IDD = 50 mA max (VDD = 2.8 V, Ta = 25°C); Backlight IF = 40 typ / 45 max mA, VF = 12.8 V (typ) |
| Operating Temperarure |
-20 ~ 70 ℃ |
| Storage Temperature |
-30 ~ 80 ℃ |
| Bezel Area (mm) |
– |
| Aspect Ratio |
1:1 |
| Connection Type |
0.5 PITCH connector |
| IC package |
– |
| Touch Panel | |
| Orientation | |
| Pixel Pitch |
– |
| Sunlight Readable |
– |
| Model |
PL040WQI-H401-R4018 |
| PPI ( pixels per inch ) |
– |
| Application |
– |
5.1-inch Flexible/Bendable OLED Display 720×1520 MIPI DSI
| Size |
5.1 inch |
|---|---|
| Pixels |
720 × 1520 |
| Interface | |
| Brightness |
390 cd/m² (typ, with CG, center); 886 cd/m² (typ, without CG, center) |
| Manufacturer |
Gesight |
| Display Type |
Flexible OLED |
| Display Mode |
Active matrix AMOLED |
| Color Depth | |
| Refresh Rate |
60 Hz |
| Viewing Angle Range |
Up/Down/Right/Left: 80° (typ) @ CR ≥ 10 (min 75°) |
| Outline L*W*H |
70.78 × 151.31 × 1.343 mm (module outline × total thickness) |
| Active Area L*W |
55.404 × 116.964 mm |
| Orientation | |
| Supply Voltage |
VDDIO: 1.62–1.98 V; VCI: 2.60–3.60 V; ELVDD: 4.40–4.80 V; ELVSS: −5.00 to −1.40 V; VCC (TSP): 2.7–3.6 V; AVDD: 5.40–7.60 V |
| Consumption |
Display (Full White, 886 nit w/o CG): VCI 3.5 mA (typ), VDDIO 22.0 mA (typ), AVDD 13.5 mA (typ), Panel EL 147 mA (typ); Touch power: Active 49.5 mW, Standby 4.29 mW, Sleep 409 µW |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−40 to +80 °C |
| Bezel Area (mm) |
Left/Right 1.10 mm each, Top/Bottom 1.80 mm each |
| Aspect Ratio |
19:9 |
| Connection Type |
Board-to-board connector (Recommended: AXE640124); Touch connector type: FOF |
| IC package |
COF |
| Touch Panel | |
| Pixel Pitch |
76.95 × 76.95 µm |
| Sunlight Readable |
– |
| Model |
BF051FBM-AK0- |
| PPI ( pixels per inch ) |
329.8 PPI |
| Application |
Smart Mobile Phone |
5.99-inch Flexible/Bendable OLED Display 1080×2160 MIPI DSI
| Size |
5.99 inch |
|---|---|
| Pixels |
1080 × 2160 |
| Interface | |
| Brightness |
390 cd/m² (typ, Normal / W L255); 351 min, 429 max |
| Manufacturer |
Gesight |
| Display Type |
Flexible OLED |
| Display Mode |
Color active matrix AMOLED module (LTPS TFT) |
| Color Depth | |
| Refresh Rate |
60 Hz |
| Viewing Angle Range |
Up/Down/Right/Left, CR ≥ 10: 80° (typ), 75° (min) |
| Outline L*W*H |
71.35 × 150.42 mm; Total thickness: 1.416 mm |
| Active Area L*W |
68.04 × 136.08 mm |
| Orientation | |
| Supply Voltage |
VCI: 2.60–3.60 V (typ 3.00 V); VDDIO: 1.62–1.98 V (typ 1.80 V); AVDD: 5.40–7.70 V (typ 6.80 V); ELVDD: 4.40–4.80 V (typ 4.60 V); ELVSS: -5.00 to -1.40 V (typ -2.40 V); TSP VCC: 2.7–3.6 V |
| Consumption |
VCI 2.0 mA typ; VDDIO 30 mA typ; AVDD 20 mA typ; Panel EL 220 mA typ. Display sleep-in: VCI 0.1 mA typ; VDDIO 1.5 mA typ. Touch power: Active 82 mW; Standby 33 mW; Sleep 165 µW |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−40 to +80 °C |
| Bezel Area (mm) |
– |
| Aspect Ratio |
18:9 |
| Connection Type |
Main FPC, B-to-B contact pads; recommended connector: 24-5857-048 |
| IC package |
GT9286-BGA |
| Touch Panel | |
| Pixel Pitch |
63 µm |
| Sunlight Readable |
– |
| Model |
BO599FF2KM |
| PPI ( pixels per inch ) |
403 ppi |
| Application |
Smart Mobile Phone |
6.52-inch Flexible/Bendable OLED Display 2520×840 MIPI DSI
| Size |
6.52 inch |
|---|---|
| Pixels |
2520 × 840 (SPR) |
| Interface | |
| Brightness |
430 nits (typ, normal mode); 700 nits (typ, HBM mode) |
| Manufacturer |
Gesight |
| Display Type |
Flexible OLED |
| Display Mode |
AMOLED |
| Color Depth | |
| Refresh Rate |
60 Hz / 90 Hz |
| Viewing Angle Range |
Full viewing angle; detailed angles TBD (Top/Bottom/Right/Left, CR > 10) |
| Outline L*W*H |
159.472 × 54.379 × 1.0 mm (H max; outline is “MOD W/O CG”) |
| Active Area L*W |
157.1976 × 52.3992 mm |
| Orientation | |
| Supply Voltage |
VDDIO: 1.65–1.95 V; VCI: 2.65–4.8 V; AVDD: 6.0–8.0 V; DVDD: 1.10–1.23 V; ELVDD: 4.6–5.0 V; ELVSS: -5.4–-1.4 V |
| Consumption |
– |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−40 to +80 °C |
| Bezel Area (mm) |
Approx. 0.99 mm (left/right) & 1.14 mm (top/bottom), computed from Outline vs Active Area |
| Aspect Ratio |
27:9 |
| Connection Type |
40-pin connector; connector model: BM035-I40-C08 |
| IC package |
COP (Driver IC location: COP) |
| Touch Panel | |
| Pixel Pitch |
0.06238 mm |
| Sunlight Readable |
– |
| Model |
PO652F2K |
| PPI ( pixels per inch ) |
407.41 PPI |
| Application |
– |
6.67-inch Flexible/Bendable AMOLED Display 1080×2400 MIPI
| Size |
6.67 inch |
|---|---|
| Pixels |
1080 (W) × 2400 (H) |
| Interface | |
| Brightness |
350–700 cd/m² (White) |
| Manufacturer |
Gesight |
| Display Type |
Flexible OLED |
| Display Mode |
AMOLED |
| Color Depth | |
| Refresh Rate |
– |
| Viewing Angle Range |
80° (Φ=0°/90°/180°/270°) |
| Outline L*W*H |
159.24 × 72.63 × 0.62 mm |
| Active Area L*W |
154.560 × 69.552 mm |
| Orientation | |
| Supply Voltage |
VCI 3.3 V; ID1 1.8 V; VDD 1.8 V; ELVSS -4.0 to 0 V (typ -3.0 V); DVDD 1.2 V; Touch VCC 3.0–3.5 V |
| Consumption |
– |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−30 to +80 °C |
| Bezel Area (mm) |
L/R total 3.078 mm (≈1.539 mm each), T/B total 4.680 mm (≈2.340 mm each) |
| Aspect Ratio |
9:20 (1080:2400) |
| Connection Type |
FPC + connector |
| IC package |
– |
| Touch Panel | |
| Pixel Pitch |
– |
| Sunlight Readable |
– |
| Model |
TA067FM01 |
| PPI ( pixels per inch ) |
~395 PPI |
| Application |
– |
7.0-inch 1080×1920 AMOLED Touch Display
| Size |
7.0 inch |
|---|---|
| Pixels |
1080 × 1920 (FHD) |
| Interface | |
| Brightness |
800 cd/m² (typ, Normal); 1000 cd/m² (typ, HBM) |
| Manufacturer |
Gesight |
| Display Type |
AMOLED |
| Display Mode |
AMOLED |
| Color Depth | |
| Refresh Rate |
50/60/120/165 Hz |
| Viewing Angle Range |
80°/80°/80°/80° (T/B/L/R, CR ≥ 10) |
| Outline L*W*H |
89.13 × 160.91 × 1.095 mm (module, with R.T); 89.1344 × 160.9056 × 0.8 mm (panel outline) |
| Active Area L*W |
87.13 × 154.91 mm (AA) |
| Orientation | |
| Supply Voltage |
VBAT: 3.8–4.5 V; VCC: 3.3 V; IOVCC: 1.8 V |
| Consumption |
4.40 W (typ, Normal); 5.84 W (typ, HBM) |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−40 to +80 °C |
| Bezel Area (mm) |
AA: L/R ≈ 1.0 mm each; T/B ≈ 3.0 mm each |
| Aspect Ratio |
9:16 |
| Connection Type |
FPC connector (FH26-39S-0.3SHW) |
| IC package |
– |
| Touch Panel | |
| Pixel Pitch |
≈ 0.0807 mm |
| Sunlight Readable |
– |
| Model |
PO700FH101GG |
| PPI ( pixels per inch ) |
315 PPI |
| Application |
Folding / Flexible AMOLED module (panel) |
7 Inch 1920×1200 IPS TFT LCD 2000 cd High Brightness
| Size |
7 inch |
|---|---|
| Pixels |
1200 (H) × RGB × 1920 (V) |
| Interface | |
| Brightness |
2000 cd/m² (typical) |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Normally Black, a-Si TFT / transmissive |
| Color Depth | |
| Refresh Rate |
60 Hz |
| Viewing Angle Range |
80°/80°/80°/80° (L/R/U/D) |
| Outline L*W*H |
111.0 × 166.0 × 3.29 mm |
| Active Area L*W |
94.5 × 151.2 mm |
| Orientation | |
| Supply Voltage |
VDDI: 1.7–2.0 V, VSP: 4.5–6.0 V, VSN: –6.0 to –4.5 V |
| Consumption |
BL: 390 mA @ 21.7 V (typ) |
| Operating Temperarure |
–20°C ~ 70°C |
| Storage Temperature |
-30 ~ 80 °C |
| Bezel Area (mm) |
25.24 (H) × 19.4 (V) x 1.925(T) mm |
| Aspect Ratio |
16:10 (H:V) |
| Connection Type |
40-pin MIPI |
| IC package |
COG |
| Touch Panel | |
| Pixel Pitch |
0.0996 x 0.0996 mm |
| Sunlight Readable |
Yes (2000 cd/m²) |
| Model |
CXW070WULM006B |
| PPI ( pixels per inch ) |
323 |
7.84 inch IPS TFT LCD Module 500cd/m² | MIPI | Industrial Grade
| Weight | 12 kg |
|---|---|
| Size |
7.84 inches |
| Pixels |
400×1280 |
| Interface | |
| Brightness |
450 cd/m² (Min), 500 cd/m² (Typ) |
| Manufacturer |
Gesight |
| Display Type |
IPS LCD ,TFT-LCM |
| Display Mode |
Normally Black, a-Si TFT / transmissive |
| Color Depth | |
| Refresh Rate |
– |
| Viewing Angle Range |
70°–80° (CR ≥10, all directions) |
| Outline L*W*H |
205.78 × 67.60 × 4.60 mm (Outline: 205.78 × 67.60; Thickness: 4.6 mm) |
| Active Area L*W |
190.08 × 59.40 mm |
| Supply Voltage |
19.2V (Typ, for backlight), 3.3V/1.8V (Logic) |
| Consumption |
24 × 192 mW (Max power dissipation) |
| Operating Temperarure |
-20°C to +70°C |
| Storage Temperature |
-30°C to +70°C |
| Bezel Area (mm) |
– |
| Aspect Ratio |
~3.2:1 (190.08:59.4) |
| Connection Type |
FPC (Flexible Printed Circuit) |
| IC package |
Suggested Driver IC: EK79030 |
| Touch Panel | |
| Pixel Pitch |
Same as Pixel Size |
| Sunlight Readable |
– |
| Model |
BRT784-4.6BL0292-24A / TM078XYHP01-00 |
| PPI ( pixels per inch ) |
~163 PPI (Calculated from resolution and active area) |
| PPI | |
| Application |
Automotive(Rearview Mirror) |
8.01-inch 2480×1860 Flexible/Bendable AMOLED Display
| Size |
8.01 inch |
|---|---|
| Pixels |
2480 × 1860 (SPR) |
| Interface | , |
| Brightness |
430 nits (typ, complete machine); 600 nits (HBM typ, complete machine) |
| Manufacturer |
Gesight |
| Display Type |
Flexible OLED |
| Display Mode |
AMOLED |
| Color Depth | |
| Refresh Rate |
60 Hz |
| Viewing Angle Range |
Up/Down/Right/Left: CR @ 80 degree = 1000 : 1 |
| Outline L*W*H |
165.89 × 126.12 × 0.778 mm (typ) |
| Active Area L*W |
162.688 × 122.016 mm |
| Orientation | |
| Supply Voltage |
VCI 3.0 V (typ); VDDIO 1.8 V (typ); AVDD 7.6 V (typ); ELVDD 4.6 V (typ); ELVSS: Normal -3.3 V / HBM -4.0 V / AOD -2 V |
| Consumption |
Display current (typ, 60 Hz, white pattern): Normal/430 nits — AVDD 38.08 mA; VCI 10.58 mA; VDDIO 117.97 mA; ELVDD 451.78 mA; ELVSS 423.01 mA. HBM/600 nits — AVDD 37.48 mA; VCI 10.52 mA; VDDIO 118.73 mA; ELVDD 619.09 mA; ELVSS 618.89 mA |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−40 to +80 °C |
| Bezel Area (mm) |
long-side bezel 1.601 mm each side; short-side bezel 2.052 mm each side |
| Aspect Ratio |
4:3 |
| Connection Type |
FPC connector; Connector Type: 5052744042 |
| IC package |
Driver IC: COP; Touch IC: FPC |
| Touch Panel | |
| Pixel Pitch |
0.0656 mm |
| Sunlight Readable |
– |
| Model |
PF801FM2480C |
| PPI ( pixels per inch ) |
387.0 PPI |
| Application |
Folding / Flexible AMOLED module (panel) |
8.01-inch Flexible/Bendable AMOLED Display 2480×1860 MIPI
| Size |
8.01 inch |
|---|---|
| Pixels |
2480 × 1860 (2K+) |
| Interface | , |
| Brightness |
Typ 430 nits (after lamination); Typ 500 cd/m² (before lamination); HBM Typ 700 nits |
| Manufacturer |
Gesight |
| Display Type |
Flexible OLED |
| Display Mode |
AMOLED |
| Color Depth | |
| Refresh Rate |
60 Hz |
| Viewing Angle Range |
Full viewing angle; TBD (Top/Bottom/Right/Left, CR > 10) |
| Outline L*W*H |
165.688 × 125.416 × TBD mm |
| Active Area L*W |
162.688 × 122.016 mm |
| Orientation | |
| Supply Voltage |
VDDIO 1.65–1.95 V; VCI 2.65–4.8 V; AVDD 6.0–8.0 V; DVDD 1.1–1.23 V; ELVDD 4.6–5.0 V; ELVSS -5.4–-1.4 V |
| Consumption |
– |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−40 to +80 °C |
| Bezel Area (mm) |
1.5 mm (L-side) / 1.7 mm (W-side) |
| Aspect Ratio |
4:3 |
| Connection Type |
BM035-I40-C08 |
| IC package |
Driver IC: COP; Touch IC: FPC |
| Touch Panel | |
| Pixel Pitch |
0.0656 mm |
| Sunlight Readable |
– |
| Model |
PF801FM2480F |
| PPI ( pixels per inch ) |
387 PPI |
| Application |
– |
8.9 Inch 4k LCD Ultra High PPI for SLA 3D Printer
| Size |
8.9 inch |
|---|---|
| Pixels |
3840(H) × 2400(V) |
| Interface | |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Normally Black |
| Color Depth | |
| Refresh Rate |
40hz |
| Viewing Angle Range |
Horizontal: 80° (typ.), Vertical: 80° (typ.) |
| Outline L*W*H |
202.0 × 133.0mm |
| Active Area L*W |
192.0 × 120.0 mm |
| Orientation | |
| Build-in Touch IC |
Not included |
| Supply Voltage |
IOVCC: 3.3V, VSP: +6V, VSN: -6V |
| Operating Temperarure |
–20°C ~ 70°C |
| Storage Temperature |
–20°C ~ 80°C |
| Bezel Area (mm) |
L/R: 5.0, U: 3.0, D: 4.0+6.0 |
| Aspect Ratio |
16:10 (H:V) |
| Connection Type |
FPC, 60-pin |
| IC package |
ST5892B |
| Touch Panel | |
| Sunlight Readable |
NO |
| Model |
GS089FBB-N10-6HP0 |
| PPI ( pixels per inch ) |
498PPI |
10.1-inch High-Brightness TFT LCD 800×1280 MIPI Display
| Size |
10.1 inch |
|---|---|
| Pixels |
800(RGB) × 1280 dots |
| Interface | |
| Brightness |
Typ 800 cd/m² (Min 750 cd/m²) @ Ib=160mA |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Normally Black |
| Color Depth | |
| Refresh Rate |
60 Hz (Frame rate condition in DC characteristics note) |
| Viewing Angle Range |
CR=10: Horizontal (R/L) Min 80°, Typ 85°; Vertical (U/D) Min 80°, Typ 85° |
| Outline L*W*H |
143 × 228.61 × 2.7 mm (Typ, tolerance ±0.2) |
| Active Area L*W |
135.36 × 216.576 mm |
| Orientation | |
| Supply Voltage |
Logic (VDDIO / IOVCC): 1.7–3.0 V (Typ 1.8 V); Analog (Vcc): 3.0–3.6 V (Typ 3.3 V) |
| Consumption |
– |
| Operating Temperarure |
-10 to +60 ℃ |
| Storage Temperature |
-20 to +70 ℃ |
| Bezel Area (mm) |
– |
| Aspect Ratio |
800:1280 = 5:8 |
| Connection Type |
FPC connector, 40 pins; Connector model: 5001-FPC0515-40RL |
| IC package |
– |
| Touch Panel | |
| Pixel Pitch |
0.1692(H) × 0.11692(V) mm |
| Sunlight Readable |
– |
| Model |
GL10PHDM800 |
| PPI ( pixels per inch ) |
– |
| Application |
– |
12.1 Inch 800×1280 TFT LCD High 1000 cd/m Brightness
| Size |
12.1 inch |
|---|---|
| Pixels |
1280 (H) × 800 (V), RGB vertical stripe |
| Interface | |
| Brightness |
1000 cd/m² (typ.) |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Normally White |
| Color Depth | |
| Refresh Rate |
50–60 Hz |
| Viewing Angle Range |
65°/65° (L/R), 50°/50° (U/D) |
| Outline L*W*H |
278.2 × 184 × 10.0 mm (typ.) |
| Active Area L*W |
261.12 × 163.2 mm |
| Orientation | |
| Build-in Touch IC |
Not included |
| Supply Voltage |
3.0–3.6 V (typ. 3.3 V) |
| Consumption |
1.6 W (typ.), 1.7 W (max) |
| Operating Temperarure |
–20°C ~ 70°C |
| Storage Temperature |
–20°C ~ 70°C |
| Aspect Ratio |
16:10 (H:V) |
| Connection Type |
Hirose DF19LA-20P-1H (signal), JST BHR-04VS-1 (backlight) |
| IC package |
LVDS receiver embedded in AUO ASIC |
| Touch Panel | |
| Sunlight Readable |
Yes (1000 nits brightness) |
| Model |
CXW121WXLM002 |
| PPI ( pixels per inch ) |
123 PPI |
