Industrial Panel refers to display panels engineered for industrial and commercial equipment where stability and long service life come first. They’re used for HMIs and control interfaces that must remain readable for long hours, so the focus is on consistent brightness and contrast, clear text rendering, wide viewing angles, and predictable image quality over time—rather than consumer-style visual effects.
Beyond image performance, industrial panels prioritize real-world integration and durability. Common requirements include extended operating temperature options, resistance to vibration and electrical noise, and mechanical designs that suit embedded mounting and maintenance. They’re often selected for factory automation, PLC/HMI terminals, test and measurement equipment, logistics and warehousing devices, kiosks, power/energy monitoring, and other environments that demand reliable 24/7 operation.
FREE SHIPPING
Fast and reliable delivery
50 DAYS RETURN
Consumer protection program
24/7 SUPPORT
If you have any questions
BEST QUALITY
Many years on the market
2.47-inch Circular TFT LCD 480×480 MIPI DSI
| Size |
2.47 inch (diagonally measured active area) |
|---|---|
| Pixels |
480RGB × 480 |
| Interface | |
| Brightness |
350 min / 400 typ cd/m² (nit) |
| Manufacturer |
Gesight |
| Display Type |
IPS LCD ,TFT-LCD |
| Display Mode |
Normally Black, Transmissive mode |
| Color Depth | |
| Refresh Rate |
60 Hz (Frame rate condition in DC characteristics note) |
| Viewing Angle Range |
CR>10: 70 min / 85 typ (H/V, U/D/L/R same) |
| Outline L*W*H |
69.19 ±0.2 (H) × 71.74 ±0.2 (V) × 2.45 ±0.15 (D) mm (no component & FPC) |
| Active Area L*W |
62.64 × 62.64 (circle) mm |
| Orientation | |
| Supply Voltage |
IOVCC: 1.65–3.3 V (typ 1.8 V); VCI: 2.5–3.6 V (typ 3.3 V) |
| Consumption |
Normal: 80 typ / 100 max mW; Standby: 260 typ µW |
| Operating Temperarure |
-10 to +60 ℃ |
| Storage Temperature |
-30 to +70 ℃ |
| Bezel Area (mm) |
– |
| Aspect Ratio |
1:1 |
| Connection Type |
FPC connector, 35-pin pin map |
| IC package |
– |
| Touch Panel | |
| Pixel Pitch |
130.5 (H) × 130.5 (V) µm |
| Sunlight Readable |
– |
| Model |
PL025C480M |
| PPI ( pixels per inch ) |
≈ 275 PPI |
| Application |
Healthcare & Industrial |
2.6-inch 240×320 AMOLED Display Module
| Size |
2.6 inch |
|---|---|
| Pixels |
240 × RGB × 320 |
| Interface | |
| Brightness |
200 cd/m² (Typ), 170 cd/m² (Min), 230 cd/m² (Max) |
| Manufacturer |
Gesight |
| Display Type |
AMOLED |
| Display Mode |
AMOLED |
| Color Depth | |
| Refresh Rate |
80 Hz (Frame Rate setting in test condition) |
| Viewing Angle Range |
160° (Min), 170° (Typ) |
| Outline L*W*H |
44.7 × 62.2 × 1.65 mm (Typ) |
| Active Area L*W |
39.60 × 52.48 mm |
| Orientation | |
| Supply Voltage |
AR_VDD = +4.6 V; AR_VSS = -4.4 V; VCI = 2.5–3.3 V; IOVCC (VDD3) = 1.65–3.3 V |
| Consumption |
260 mW (Typ), 300 mW (Max) @ 30% pixels on |
| Operating Temperarure |
−30 to +70 °C |
| Storage Temperature |
−40 to +80 °C |
| Bezel Area (mm) |
L/R = 2.55 mm; T/B = 4.86 mm (calculated from Outline vs Active Area) |
| Aspect Ratio |
3:4 (240:320) |
| Connection Type |
– |
| IC package |
COG assembly |
| Touch Panel | |
| Pixel Pitch |
0.055 × 0.164 mm |
| Sunlight Readable |
– |
| Model |
AMS260DN01 |
| PPI ( pixels per inch ) |
154 PPI |
| Application |
Cell phone etc. |
3.16-inch TFT-LCD Display Module 820×320 Parallel RGB
| Size |
3.16 inch |
|---|---|
| Pixels |
820 RGB × 320 |
| Interface | |
| Brightness |
550 cd/m² (typ.) |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Transmission mode, Normally black |
| Color Depth | |
| Refresh Rate |
– |
| Viewing Angle Range |
80° (CR ≥ 10) for each direction (U/D/L/R) |
| Outline L*W*H |
76.6 × 31.2 × 2.4 mm |
| Active Area L*W |
65.65 × 26.4 mm |
| Supply Voltage |
VCI: 2.8–3.6 V (typ. 3.3 V); IOVCC: 1.65–3.3 V (typ. 1.8 V) |
| Consumption |
Idd: 40 mA (typ.) |
| Operating Temperarure |
-20 to 70 °C |
| Storage Temperature |
-30 to 80 °C |
| Bezel Area (mm) |
5.475 mm (left/right), 2.4 mm (top/bottom) |
| Aspect Ratio |
820:320 |
| Connection Type |
– |
| IC package |
– |
| Touch Panel | |
| Orientation | |
| Pixel Pitch |
0.0825 × 0.0285 mm |
| Sunlight Readable |
– |
| Model |
PL0316IV0-SV1-RGB |
| PPI ( pixels per inch ) |
278.6 PPI (≈279 PPI) |
| Application |
Virtual Reality Device；Augmented Reality Device |
5.0-inch Circular TFT LCD 1080×1080 MIPI DSI
| Size |
5.0 inch |
|---|---|
| Pixels |
1080(RGB) × 1080 |
| Interface | |
| Brightness |
400 cd/m² (Typ.) |
| Manufacturer |
Gesight |
| Display Type |
IPS LCD ,TFT-LCD |
| Display Mode |
Normally Black, Transmissive mode |
| Color Depth | |
| Refresh Rate |
60 Hz |
| Viewing Angle Range |
U/D/L/R free viewing direction |
| Outline L*W*H |
136.531 × 132.208 × 1.98 mm |
| Active Area L*W |
127.008 × 127.008 mm (circle) |
| Orientation | |
| Supply Voltage |
IOVCC 1.8 V (typ); VSP +5.0 V (typ); VSN -5.0 V (typ); LED VF 38.4 V (typ); LED IF 20 mA (typ) |
| Consumption |
Backlight power 0.744 W (typ); 0.768 W (max) |
| Operating Temperarure |
-20 to +60 °C |
| Storage Temperature |
-30 to +75 °C |
| Bezel Area (mm) |
– |
| Aspect Ratio |
1:1 |
| Connection Type |
Board-to-board connector |
| IC package |
– |
| Touch Panel | |
| Pixel Pitch |
0.1176 × 0.1176 mm |
| Sunlight Readable |
– |
| Model |
PL050HDC |
| PPI ( pixels per inch ) |
305 |
| Application |
– |
7-inch 1024X600 TFT LCD Module LVDS Industrial Panel
| Size |
7 inch |
|---|---|
| Pixels |
1024X600 |
| Interface | |
| Brightness |
300 cd/m² (typ.) |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Normally Black |
| Color Depth | |
| Refresh Rate |
60 Hz |
| Viewing Angle Range |
70°–80° (CR≥10, all directions) |
| Outline L*W*H |
165 mm × 100 mm × 3.5 mm |
| Active Area L*W |
154.21 mm × 85.92 mm |
| Orientation | |
| Build-in Touch IC |
Not included |
| Supply Voltage |
3.3V (VDDIN), 5–12V (VLED for backlight) |
| Operating Temperarure |
–10°C ~ 50°C |
| Storage Temperature |
–20°C ~ 60°C |
| Aspect Ratio |
16:9 (H:V) |
| Connection Type |
20-pin interface |
| Touch Panel | |
| Model |
CXW070WSLM005 |
| PPI ( pixels per inch ) |
149 PPI |
8.0-inch TFT LCD 800×1280 MIPI Display
| Size |
8 inch |
|---|---|
| Pixels |
800(RGB) × 1280 dots |
| Interface | |
| Brightness |
Typ 250 cd/m² (Min 220) |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Normally Black |
| Color Depth | |
| Refresh Rate |
60 Hz (Frame rate condition in DC characteristics note) |
| Viewing Angle Range |
L/R/U/D：Min 80°, Typ 85°（CR=10） |
| Outline L*W*H |
114.6 × 184.1 × 2.6 mm |
| Active Area L*W |
107.64(H) × 172.22(V) mm |
| Orientation | |
| Supply Voltage |
VCC(analog): 3.0–3.6V (Typ 3.3V)；VDDIO(logic): 1.7–3.0V (Typ 1.8V) |
| Consumption |
– |
| Operating Temperarure |
-10 to +60 ℃ |
| Storage Temperature |
-20 to +70 ℃ |
| Bezel Area (mm) |
Bezel Area (mm): **L/R: 3.48 mm each; T/B: 5.94 mm each** |
| Aspect Ratio |
16:10 |
| Connection Type |
31-pin FPC (pinout: 1–31) |
| IC package |
– |
| Touch Panel | |
| Pixel Pitch |
0.1506(H) × 0.1432(V) mm |
| Sunlight Readable |
– |
| Model |
PL801WXGAM |
| PPI ( pixels per inch ) |
≈188.68 PPI |
| Application |
– |
10.1-inch High-Brightness TFT LCD 800×1280 MIPI Display
| Size |
10.1 inch |
|---|---|
| Pixels |
800(RGB) × 1280 dots |
| Interface | |
| Brightness |
Typ 800 cd/m² (Min 750 cd/m²) @ Ib=160mA |
| Manufacturer |
Gesight |
| Display Type |
TFT-LCD |
| Display Mode |
Normally Black |
| Color Depth | |
| Refresh Rate |
60 Hz (Frame rate condition in DC characteristics note) |
| Viewing Angle Range |
CR=10: Horizontal (R/L) Min 80°, Typ 85°; Vertical (U/D) Min 80°, Typ 85° |
| Outline L*W*H |
143 × 228.61 × 2.7 mm (Typ, tolerance ±0.2) |
| Active Area L*W |
135.36 × 216.576 mm |
| Orientation | |
| Supply Voltage |
Logic (VDDIO / IOVCC): 1.7–3.0 V (Typ 1.8 V); Analog (Vcc): 3.0–3.6 V (Typ 3.3 V) |
| Consumption |
– |
| Operating Temperarure |
-10 to +60 ℃ |
| Storage Temperature |
-20 to +70 ℃ |
| Bezel Area (mm) |
– |
| Aspect Ratio |
800:1280 = 5:8 |
| Connection Type |
FPC connector, 40 pins; Connector model: 5001-FPC0515-40RL |
| IC package |
– |
| Touch Panel | |
| Pixel Pitch |
0.1692(H) × 0.11692(V) mm |
| Sunlight Readable |
– |
| Model |
GL10PHDM800 |
| PPI ( pixels per inch ) |
– |
| Application |
– |
