Size	1.43 inch
Pixels	466 × 466
Interface	QSPI
Brightness	700 cd/m² (typ, Ta=25℃, all-white, θ=0)
Manufacturer	Gesight
Display Type	AMOLED
Display Mode	AMOLED / LTPS Glass
Color Depth	16.7M colors (24-bit)
Refresh Rate	45 Hz (Frame Frequency fFRM)
Viewing Angle Range	88° (Up/Down/Right/Left, Cr≥200)
Outline LWH	44.75 × 44.75 × 2.58 mm
Active Area L*W	36.35 × 36.35 mm
Orientation	Landscape
Supply Voltage	VCC 2.7–3.6 V; IOVCC 1.65–3.3 V; ELVDD 3.25–3.35 V; ELVSS -3.35–-3.25 V
Consumption	Full white (Sleep out): IVCC 2 mA typ (4 mA max); IIOVCC 1.5 mA typ (3 mA max); IELVDD/ELVSS 13 mA typ (19.5 mA max)
Operating Temperarure	−30 to +70 °C
Storage Temperature	−30 to +80 °C
Bezel Area (mm)	4.20 mm per side
Aspect Ratio	1:1
Connection Type	FPC
IC package	COF
Touch Panel	On-cell
Pixel Pitch	78 × 78 µm
Sunlight Readable	–
Model	TR143R2404A
PPI ( pixels per inch )	461 PPI
Application	Touch interface pins listed; Touch signals present

Size	1.47 inch
Pixels	194 (W) × 368 (H) (Real RGB arrangement)
Interface	QSPI , I2C
Brightness	450 nits typ (Luminance: 400 min / 450 typ / 500 max cd/m²)
Manufacturer	Gesight
Display Type	AMOLED
Display Mode	AMOLED
Color Depth	16.7M colors (24-bit)
Refresh Rate	60 Hz (Normal mode); 15 Hz (Idle mode)
Viewing Angle Range	Left/Right/Top/Bottom: 80° min / 85° typ (Cr ≥ 200)
Outline LWH	LTPS Glass outline: 19.36 (V) × 36.17 (W) mm; Glass thickness (LTPS/Encap./POL): 0.2/0.3/0.147 mm
Active Area L*W	17.46 × 33.12 mm
Orientation	Portrait
Supply Voltage	VCI 3.3 V (3.2–3.4 V); VDDIO 1.8 V (1.7–1.9 V); ELVDD 3.3 V (3.2–3.4 V); ELVSS -3.3 V (-3.4–-3.2 V); TP_VDD 2.8 V (typ); TP_OPT_VDDIO 1.8 V (typ)
Consumption	Normal: 110 typ / 130 max mW (450 nits @ 60 Hz); Idle: 6.5 typ / 8.2 max mW (50 nits @ 15 Hz); Standby: 50 µW max
Operating Temperarure	−30 to +70 °C
Storage Temperature	−30 to +80 °C
Bezel Area (mm)	1.90 mm (V total = 19.36 − 17.46); 3.05 mm (W total = 36.17 − 33.12)
Aspect Ratio	194:368
Connection Type	FPC (Main FPC Bonding PAD), 34 pins
IC package	COF
Touch Panel	On-cell
Pixel Pitch	90 × 90 µm
Sunlight Readable	–
Model	E1473AC63.B
PPI ( pixels per inch )	283 PPI
Application	Display/Touch terminals for Smart Watch

Size	1.78 inch
Pixels	368(W) × 448(H) (Real RGB)
Interface	MIPI DSI , SPI
Brightness	350 cd/m² (Typ.)
Manufacturer	Gesight
Display Type	AMOLED
Display Mode	AMOLED
Color Depth	16.7 M (8-bit)
Refresh Rate	60 Hz (Typ., Normal Mode); 15 Hz (Idle Mode)
Viewing Angle Range	80° (Top/Bottom/Right/Left, CR ≥ 1000)
Outline LWH	LTPS glass outline: 30.6 × 37.99 mm; Encapsulation glass outline: 30.6 × 37.24 mm; Glass thickness (LTPS/Encap.): 0.2 / 0.3 mm
Active Area L*W	28.7 × 34.94 mm
Orientation	Portrait
Supply Voltage	Vbat: 2.9–4.8 V (Typ. 3.7 V); VDDIO: 1.65–1.95 V (Typ. 1.8 V)
Consumption	Normal mode: 186–210 mW; Idle mode: 12–16 mW; Standby mode: Max 50 μW
Operating Temperarure	−30 to +70 °C
Storage Temperature	−40 to +80 °C
Bezel Area (mm)	–
Aspect Ratio	23:28 (368:448)
Connection Type	–
IC package	–
Touch Panel	On-cell
Pixel Pitch	78 × 78 μm
Sunlight Readable	–
Model	ED178AM368MS
PPI ( pixels per inch )	326 PPI
Application	Smart Watch

Size	2.04 inch
Pixels	368 × 448
Interface	QSPI
Brightness	700 cd/m² (typ.)
Manufacturer	Gesight
Display Type	AMOLED
Display Mode	AMOLED / LTPS
Color Depth	16.7M colors (24-bit)
Refresh Rate	45 Hz (Frame Frequency)
Viewing Angle Range	Up/Down/Right/Left: 88 deg (Cr ≥ 200)
Outline LWH	44.46 × 34.64 × 2.58 mm
Active Area L*W	39.98 × 33.74 mm
Orientation	Portrait
Supply Voltage	VCC: 2.7–3.6 V (typ. 3.3 V); IOVCC: 1.65–3.3 V (typ. 1.8 V); ELVDD: 3.25–3.35 V (typ. 3.3 V); ELVSS: -3.35–-3.25 V (typ. -3.3 V)
Consumption	IVCC: 2 mA (typ., full white, sleep out); IIOVCC: 1.5 mA (typ.); IELVDD/ELVSS: 13 mA (typ.)
Operating Temperarure	−30 to +70 °C
Storage Temperature	−30 to +80 °C
Bezel Area (mm)	–
Aspect Ratio	23:28
Connection Type	FPC
IC package	COF
Touch Panel	On-cell
Pixel Pitch	78 × 78 µm
Sunlight Readable	–
Model	PO204RT448S
PPI ( pixels per inch )	284 PPI
Application	Smart Watch
